If you are looking for a compact, dependable and versatile diesel power unit, the Lister LPW3 diesel engine is an engine worth considering. The LPW3 belongs to the Lister Petter LPW engine family and uses a three-cylinder, naturally aspirated diesel configuration with direct fuel injection.
At Buchi Trading Boat Engines, we understand that customers buying marine and industrial engines need more than just an engine name. They need reliable technical information, compatibility guidance, shipping support and confidence that the engine matches their application.
This guide explains the Lister LPW3 diesel engine, its technical characteristics, applications, maintenance considerations and important points to check before purchasing.
Table of Contents
- What Is the Lister LPW3 Diesel Engine?
- Lister LPW3 Diesel Engine Technical Specifications
- Key Features of the LPW3
- Performance and Torque
- Applications of the Lister LPW3
- Lister LPW3 for Marine Applications
- Lister LPW3 for Industrial Equipment
- Fuel Injection and Engine Design
- Cooling and Lubrication
- Maintenance Requirements
- Advantages of the LPW3
- Buying a Lister LPW3 Diesel Engine
- Shipping and Export
- Frequently Asked Questions
- Conclusion
What Is the Lister LPW3 Diesel Engine?
The Lister LPW3 diesel engine is a three-cylinder diesel engine manufactured as part of the Lister Petter LPW family. According to Lister Petter’s technical data, the LPW3 has a 1.395-litre displacement, an 86 mm bore, and an 80 mm stroke. It uses direct fuel injection and natural aspiration.
The engine is designed around a relatively simple mechanical architecture, making it suitable for applications where durability, serviceability and dependable operation are important.
The LPW range also includes two-cylinder and four-cylinder versions, allowing equipment manufacturers and operators to select an engine according to their required power and installation requirements.
Lister LPW3 Diesel Engine Technical Specifications
| Specification | Lister LPW3 |
|---|---|
| Engine model | LPW3 |
| Fuel | Diesel |
| Number of cylinders | 3 |
| Cylinder arrangement | Inline 3-cylinder |
| Fuel injection | Direct injection |
| Aspiration | Naturally aspirated |
| Bore | 86 mm |
| Stroke | 80 mm |
| Displacement | 1.395 litres |
| Compression ratio | 18.5:1 |
| Firing order | 1-2-3 |
| Rotation at flywheel end | Anti-clockwise |
| Minimum full-load speed | 1,500 rpm |
| Flywheel ring gear teeth | 96 |
| Maximum gear-end PTO | 12 kW / 16 bhp |
| Maximum side-load PTO | 8.0 kW / 10.7 bhp |
| Oil pressure at 3,000 rpm | Approximately 2.0 bar |
| Oil pressure at idle | Approximately 1.0 bar |
These specifications are from Lister Petter’s current LPW technical data documentation. Exact output and configuration can vary depending on the specific build, governor, cooling arrangement and application.
Key Features of the Lister LPW3
Three-Cylinder Configuration
The three-cylinder configuration provides a useful balance between compact size, smooth operation and practical power delivery. Compared with a larger four-cylinder engine, a three-cylinder design can help reduce overall engine size and installation requirements.
Direct Fuel Injection
The LPW3 uses direct fuel injection. Direct injection is important because fuel is injected directly into the combustion chamber, supporting efficient combustion and practical diesel-engine performance.
Naturally Aspirated Design
The LPW3 is naturally aspirated rather than turbocharged. This relatively straightforward design can be advantageous for applications where simplicity and ease of maintenance are important.
Compact Displacement
With a displacement of approximately 1.395 litres, the engine occupies a relatively compact position within the LPW family. Its dimensions and mounting arrangement should nevertheless be checked against the intended replacement engine before purchase.
Mechanical Simplicity
For many equipment owners, a straightforward diesel engine design is attractive because routine inspection and maintenance can be easier than with more electronically complex modern engines.
Performance and Torque
The Lister Petter technical data lists LPW3 torque figures across different operating speeds. The published variable-speed torque data shows approximately 71.9 Nm at 1,500 rpm, rising to about 75.9 Nm at 2,000 rpm, before decreasing at higher speeds.
This torque characteristics makes the engine useful for equipment requiring steady mechanical power rather than high-performance acceleration.
The actual usable output depends on the engine configuration, rated speed, governor setting, accessories and application.
When purchasing an LPW3, buyers should therefore avoid relying only on the model name. It is important to confirm the engine’s identification plate, specification, mounting arrangement and intended duty.
Applications of the Lister LPW3
The LPW3 can be considered for various applications requiring a compact diesel power source.
Potential applications include:
- Marine auxiliary equipment
- Small commercial vessels
- Fishing and work boats
- Pumps
- Generators
- Agricultural machinery
- Construction equipment
- Industrial machinery
- Hydraulic equipment
- Mechanical power units
- Special-purpose machinery
The exact suitability depends on the engine configuration and the equipment manufacturer’s requirements.
Lister LPW3 for Marine Applications
The Lister LPW3 diesel engine can be relevant to marine applications where a compact diesel power unit is required. However, buyers should distinguish between an industrial LPW3 and a marine-configured engine.
A marine installation can require specific components such as:
- Marine cooling system
- Marine exhaust arrangement
- Heat exchanger
- Marine gearbox
- Appropriate engine mounts
- Raw-water pump
- Marine control system
- Suitable alternator
- Marine-grade electrical components
For this reason, customers should provide the vessel type, existing engine model, gearbox information and available engine-bay dimensions when requesting an LPW3 for a marine project.
This helps determine whether the available engine configuration is appropriate.
Lister LPW3 for Industrial Equipment
The LPW engine family is also documented by Lister Petter for industrial applications. The manufacturer’s industrial technical documentation lists the LPW3 as a three-cylinder, naturally aspirated, direct-injection engine with 1.395 litres displacement.
Its compact three-cylinder layout can make it useful for equipment where installation space is limited.
Depending on the build, an LPW3 can be considered for applications such as pumps, compact generating equipment and other mechanical power systems.
Fuel Injection and Engine Design

Fuel injection is one of the most important systems in any diesel engine.
The LPW3 uses direct fuel injection, which means fuel is delivered directly into the combustion chamber. The engine’s 18.5:1 compression ratio supports the compression-ignition process used by diesel engines.
Correct fuel quality and regular replacement of fuel filters are important for protecting the injection system.
When purchasing a used Lister LPW3, buyers should inspect:
- Injector condition
- Fuel pump operation
- Fuel lines
- Fuel filters
- Signs of fuel leakage
- Cold-start behavior
- Exhaust smoke
- Engine oil condition
These checks can provide useful information about the condition of an engine before installation.
Cooling and Lubrication
Engine cooling and lubrication are essential for reliable operation.
Before installing an LPW3, the cooling arrangement should be verified against the intended application. Marine installations in particular require the correct cooling configuration and plumbing.
Lubricating oil should also be maintained at the correct level and replaced according to the engine’s operating and maintenance requirements.
Lister Petter provides operation and maintenance documentation for its products, including safety and service information.
Maintenance Requirements
Regular maintenance can significantly influence diesel engine service life.
For an LPW3, maintenance planning should include:
Engine Oil
Check oil level regularly and use oil that meets the manufacturer’s requirements for the specific engine and operating conditions.
Oil Filter
Replace the oil filter according to the appropriate service schedule.
Fuel Filter

Clean fuel is particularly important for diesel injection equipment. Replace fuel filters at the recommended service interval.
Air FilterA restricted air filter can reduce engine performance and increase smoke. Inspect and replace or clean the filter according to its design.
Cooling System
Check coolant, hoses, pumps, belts and heat exchangers where applicable.
Exhaust System
Inspect the exhaust for leaks, excessive restriction and corrosion.
Belts and Hoses
Rubber components should be inspected for cracking, deterioration and looseness.
Battery and Starting System
For electric-start installations, check the battery, cables, starter motor and charging system.
Advantages of the Lister LPW3
The LPW3 has several characteristics that can make it attractive for replacement and equipment projects.
Compact three-cylinder design: Its three-cylinder layout provides a practical compromise between size and power.
Naturally aspirated: The absence of a turbocharger simplifies the basic air-intake system.
Direct injection: Direct fuel injection is an established diesel-engine configuration.
Moderate displacement: The 1.395-litre displacement makes the engine suitable for applications where a compact diesel is required.
Serviceability: The relatively straightforward design can be attractive to operators who value accessible mechanical maintenance.
Flexible applications: Depending on configuration, LPW engines can serve industrial and other mechanical-power applications.
Buying a Lister LPW3 Diesel Engine
When searching for a Lister LPW3 diesel engine for sale, buyers should confirm more than the engine model.
Before placing an order, ask for:
- Engine model and identification details
- Engine condition
- New, rebuilt or used status
- Running-test information
- Engine photographs
- Hours, where available
- Cooling configuration
- Starting system
- Flywheel specification
- Gearbox compatibility
- Dimensions
- Shipping weight
- Export packaging
- Warranty terms
For a replacement project, provide the seller with photographs of your existing engine. This can make identification and compatibility checking easier.
At Buchi Trading Boat Engines, customers can discuss their engine requirements and application before arranging an engine purchase.
Shipping and Export
International engine buyers need to consider packaging and transportation as part of the purchase.
A diesel engine should be appropriately protected against movement, impact, moisture and contamination during transportation. Wooden crates or suitable export packaging may be required depending on the shipping method and destination.
For international buyers, useful shipping information includes:
- Engine dimensions
- Crated dimensions
- Net weight
- Gross weight
- Port of loading
- Destination port
- Shipping method
- Export documentation
- Commercial invoice
- Packing list

Buchi Trading Boat Engines can assist customers who are sourcing marine and industrial engines for international projects.
Frequently Asked Questions
Is the Lister LPW3 a three-cylinder engine?
Yes. The Lister Petter LPW3 has three cylinders. Its published displacement is 1.395 litres.
Is the LPW3 turbocharged?
No. The standard LPW3 specification is naturally aspirated.
What is the LPW3 bore and stroke?
The published bore is 86 mm and the stroke is 80 mm.
What is the LPW3 displacement?
The Lister Petter LPW3 has a total cylinder capacity of 1.395 litres, or approximately 85.13 cubic inches.
What is the LPW3 firing order?
The published firing order is 1-2-3.
Can the LPW3 be used in a boat?
The suitability depends on the particular marine configuration and installation. Customers should verify cooling, exhaust, gearbox, mounting and power requirements before installation.
Where can I buy a Lister LPW3 diesel engine?
For availability, configuration and international shipping information, contact Buchi Trading Boat Engines and provide the application and engine requirements.
Conclusion
The Lister LPW3 diesel engine is a compact three-cylinder diesel power unit featuring direct fuel injection, natural aspiration, 1.395-litre displacement and an 18.5:1 compression ratio. Lister Petter’s published technical data also lists an 86 mm bore, 80 mm stroke and 1-2-3 firing order.
Its relatively straightforward design makes it relevant to a range of industrial and mechanical applications, while the correct marine configuration can be considered for suitable boat projects.
If you are looking for a Lister LPW3 diesel engine for sale, make sure you confirm the exact specification, condition, mounting arrangement, cooling system, flywheel, gearbox compatibility and shipping requirements before purchasing.
For engine sourcing, replacement projects and international enquiries, Buchi Trading Boat Engines can help you identify the appropriate engine configuration for your application.
